LIK-N2HT3-P01 | Vertical Energy Storage All-in-One
LIK-N2HT3-P01 | Vertical Energy Storage All-in-One
LIK-N2HT3-P01 | Vertical Energy Storage All-in-One
LIK-N2HT3-P01 | Vertical Energy Storage All-in-One
LIK-N2HT3-P01 | Vertical Energy Storage All-in-One
LIK-N2HT3-P01 | Vertical Energy Storage All-in-One
LIK-N2HT3-P01 | Vertical Energy Storage All-in-One
LIK-N2HT3-P01 | Vertical Energy Storage All-in-One

LIK-N2HT3-P01 | Vertical Energy Storage All-in-One

$0.00

The LIK-N2HT3-P01 vertical all-in-one energy storage system combines LiFePO₄ battery modules with a high-efficiency inverter in a compact, modern floor-standing unit. It’s ideal for residential, small commercial, and backup energy use. With 100% new A-grade lithium cells, the system supports over 6000 cycles at 80% DOD and delivers safe, efficient, and reliable power anytime. Built-in smart BMS, LCD display, and plug-and-play design make setup easy, while hybrid integration allows seamless use with solar, grid, or diesel backup.

Vertical Energy Storage All-in-One | Product Highlights

  • All-in-One vertical design
  • Smart BMS for real-time monitoring and safety
  • LCD screen for status, power switch
  • Support hybrid power supply: compatible with solar energy, grid, diesel/gas generators
Available in:5kWh+3kW

*Send an inquiry to get a quote from the manufacturer immediately!
Specification LIK-N2HT3-P01 (5kWh + 3kW) LIK-N2HT5-P01 (5kWh + 5kW) LIK-N2HT11-P01 (14kWh + 11kW)
Battery Voltage 25.6V 25.6V 51.2V
Battery Capacity 200Ah 200Ah 280Ah
Energy 5.12kWh 5.12kWh 14.33kWh
Inverter Power 3kW 5kW 11kW
Dimensions (mm) 555 × 295 × 800 555 × 295 × 800 1130 × 500 × 330
Weight 60kg 65kg 125kg
Max Charge/Discharge Current 100A 100A 150A
Rated Input Voltage (AC) 220V / 230V 220V / 230V 220V / 230V
Input Voltage Range (170Vac – 280Vac) ± 2% (170Vac – 280Vac) ± 2% (170Vac – 280Vac) ± 2%
AC Frequency 50Hz / 60Hz 50Hz / 60Hz 50Hz / 60Hz
AC Efficiency 95% 95% 95%
Max Bypass Overload Current 40A 40A 40A
Output Waveform Pure sine wave Pure sine wave Pure sine wave
Rated Output Power (Inverter) 3kW 5kW 11kW
Power Factor 1 1 1
Output Voltage 220 / 230 / 240V ± 5% 220 / 230 / 240V ± 5% 220 / 230 / 240V ± 5%
Output Frequency 50 ± 0.3Hz / 60 ± 0.3Hz 50 ± 0.3Hz / 60 ± 0.3Hz 50 ± 0.3Hz / 60 ± 0.3Hz
Inverter Efficiency 92% 92% 92%
Max PV Open Circuit Voltage 500Vdc 500Vdc 500Vdc
PV Operating Voltage Range 60~500Vdc 60~500Vdc 60~500Vdc
Max PV Charging Current 100A 100A 150A



Advanced Integrated Energy Storage System for Home and Commercial Applications

The LIK-N2HT-P01 Series (including 5kWh+3kW, 5kWh+5kW, and 14kWh+11kW models) is a state-of-the-art all-in-one energy storage solution developed for residential and light commercial use. Engineered with high-performance LiFePO₄ batteries, high-efficiency pure sine wave inverters, and an intelligent MPPT solar charge controller, this series offers exceptional energy reliability and system stability.

Each unit integrates a modular design, featuring battery capacities ranging from 5.12kWh to 14.33kWh and inverter outputs from 3kW to 11kW. The system supports wide PV input voltages (60~500Vdc), high charge/discharge currents up to 150A, and seamless on/off-grid switching, ensuring uninterrupted power for various applications such as home backup, solar self-consumption systems, small business support, and off-grid cabins.

Precision-manufactured with robust materials, the enclosures are compact and durable, meeting international electrical and safety standards. Advanced battery management systems (BMS) protect against overvoltage, overcurrent, short circuit, and temperature fluctuations—ensuring long service life and over 6000 cycles at 80% DOD.

LIK-N2HT-P01 Series All-in-One Energy Storage System High-Performance Design, Precision Manufacturing, Factory-Backed Reliability.

Liking Energy’s LIK-N2HT-P01 series represents a new generation of vertical all-in-one energy storage systems, integrating LiFePO₄ battery packs with high-efficiency inverters. Built with our in-house expertise and manufactured under rigorous quality control protocols, this series—available in 5kWh+3kW, 5kWh+5kW, and 14kWh+11kW configurations—offers flexible and scalable solutions for residential, commercial, and off-grid power needs. Each unit is crafted using A-grade lithium iron phosphate cells known for long cycle life and safety, combined with smart BMS protection and precise inverter tuning.
Our factory leverages advanced automation, certified production lines, and strict process standards to ensure stable output and fast delivery. From battery cell stacking to system-level testing, every stage follows global best practices. The compact, elegant, and mobile floor-standing design further reflects our commitment to user convenience, intelligent energy, and sustainable innovation. With Liking Energy, you don’t just get a product—you get factory-strength assurance and long-term energy peace of mind.

All-in-One Power Solution with Premium LiFePO₄ and Modular Inverter Integration

ntegrated Battery + Inverter Design

Liking Energy’s all-in-one system combines a high-performance lithium battery module with a built-in 6kW inverter, streamlining installation and simplifying usage. It eliminates the need for complex wiring and external inverters, making it a true plug-and-play solution for home energy storage.
